Protections for push button switches
These caps are used to protect front mounted push button switches. They are suitable for Indoor and Outdoor applications.
They arewidelyused for machine tools, small portable equipment, load carriers, high pressure cleaning systems, equipmentexteriors, ....
SPECIAL FEATURES OF BUTTON SWITCH PROTECTIONS
These protections are designed to protect your button switches against water infiltration, dust, oils, grease, etc.
Whether for indoor or outdoor use, these caps ensure and guarantee flawless operation of your equipment.
The silicone protection is resistant to the most difficult conditions and by its design prevents any intrusion of liquids or foreign bodies.
TECHNICAL DATA OF CAPS FOR PUSH BUTTON SWITCH
| Reference | Thread | Not | Design | Max height of the lever | Base Width (A) | Max diameter of the lever (T) | Height (H) | Material | Durometer |
|---|---|---|---|---|---|---|---|---|---|
| IL100 | UNC | 7/8-32 UNEF-2B | 0.475" | 1.135D | 0.740" | 0.875" | silicone | 60 | |
| OP715 | UNC | 15/32-32 UNS-2B | D | .625H | 0.250" | 0.55" | silicone | 60 | |
| OP716 | UNC | 7/16-28 UNEF-2B | D | .625H | 0.250" | 0.55" | silicone | 60 | |
| PH700 | UNC | 15/32-32 UNS-2B | AND | 0.300" | .625H | 0.390" | 0.57" | silicone | 60 |
| PH701 | Metric | M12 x 1.00 | AND | 0.480" | .625H | 0.398" | 0.75" | silicone | 60 |
| PH702M | UNC | 15/32-32 UNS-2B | AND | 0.480" | .625H | 0.420" | 0.75" | silicone | 60 |
| PH703W | UNC | 1/2-32 UNS-2B | AND | 0.300" | .650H | 0.390" | 0.565" | silicone | 60 |
| PH704 | Metric | M12 x 1.00 | AND | 0.300" | .625H | 0.390" | 0.57" | silicone | 60 |
| PH705 | UNC | 10-56 UNS-2B | AND | 0.180" | .375H | 0.150" | 0.320" | silicone | 60 |
| PH706 | UNC | 1/4-32 UNEF-2B | AND | 0.180" | .375H | 0.188" | 0.320" | silicone | 60 |
| PH707 | UNC | 1/4-40 UNS-2B | AND | 0.180" | .375H | 0.180" | 0.320" | silicone | 60 |
| PH708 | UNC | 1/2-32 UNS-2B | AND | 0.205" | .625H | 0.390" | 0.57" | silicone | 60 |
| PH709 | Metric | M12 x 0.75 | AND | 0.300" | .625H | 0.390" | 0.57" | silicone | 60 |
| PH710 | UNC | 7/16-28 UNEF-2B | AND | 0.480" | .625H | 0.390" | 0.75" | silicone | 60 |
| PH711 | UNC | 15/32-32 UNS-2B | AND | 0.530" | .625H | 0.420" | 0.815" | silicone | 60 |
| PH716 | UNC | 7/16-32 UN-2B | AND | 0.480" | .625H | 0.390" | 0.75" | silicone | 60 |
| PH717 | UNC | 5/8-24 UNEF-2B | AND | 0.281" | .750H | 0.515" | 0.609" | silicone | 60 |
| PH718 | UNC | 1/2-32 UNS-2B | AND | 0.188" | .625H | 0.390" | 0.55" | silicone | 60 |
| PR729 | UNC | 3/8-24 UNF-2B | F | 0.325" | .625D | 0.310" | 0.616" | silicone | 60 |
| PR727 | UNC | 3/8-27 UNS-2B | F | 0.325" | .625D | 0.310" | 0.616" | silicone | 60 |
| PR728 | UNC | 3/8-32 UNEF-2B | F | 0.325" | .625D | 0.310" | 0.616" | silicone | 60 |
| PH702 | UNC | 15/32-32 UNS-2B | AND | 0.480" | .625H | 0.390" | 0.75" | silicone | 60 |
| PR731 | Metric | M9 x 0.75 | F | 0.325" | 0.625D | 0.310" | 0.616" | silicone | 50 |
| PH724 | UNC | 3/8-24 UNF-2B | AND | 0.550" | 0.5H | 0.330" | 0.695" | silicone | 50 |
| PH725 | Metric | M16 x 1.00 | AND | 0.300" | 0.78H | 0.590" | 0.500" | Urethane | 85 |
| PH721 | UNC | 3/8-27 UNS-2B | AND | 0.395" | 0.5H | 0.300" | 0.653" | Silicone | 50 |
| PH722 | Metric | M11 x 1.00 | AND | 0.480" | 0.625H | 0.390" | 0.75" | Silicone | 50 |
| PH723 | UNC | 8-40 UNS-2B | AND | 0.188" | 0.265H | 0.120" | 0.297" | Silicone | 50 |
| PR729 | UNC | 3/8-24 UNF-2B | F | 0.325" | 0.625D | 0.310" | 0.616" | Silicone | 50 |
